Product Details
Place of Origin: Zhejiang, China
Brand Name: Longer
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: $18,000.00 - $20,000.00/sets
Plastic Processed: |
PET |
Condition: |
New |
Application: |
Bottle |
Voltage: |
380V/50HZ |
Dimension(L*W*H): |
2050*1400*1800 (mm) |
Weight (KG): |
2200 KG |
Automation: |
Semi-automatic |
Warranty: |
1 Year |
Key Selling Points: |
Easy To Operate |
Applicable Industries: |
Food & Beverage Factory |
Machinery Test Report: |
Provided |
Video Outgoing-inspection: |
Provided |
Warranty Of Core Components: |
1 Year |
Core Components: |
Motor, PLC, Engine, Gearbox |
Automatic: |
Yes |
After-sales Service Provided: |
Engineers Available To Service Machinery Overseas |
Advanced Technology: |
Import Assistant |
Computer Control: |
Blowing Under 1.5L Bottles |
Blowing PP/PE/PET: |
Blue |
Japan Action Valve: |
Japan Blow Valve |
Japan Cylinder: |
Infrared Heating |
Imported Frequency Converter: |
High-speed |
Gold Metal: |
Made In Huangyan |
Plastic Processed: |
PET |
Condition: |
New |
Application: |
Bottle |
Voltage: |
380V/50HZ |
Dimension(L*W*H): |
2050*1400*1800 (mm) |
Weight (KG): |
2200 KG |
Automation: |
Semi-automatic |
Warranty: |
1 Year |
Key Selling Points: |
Easy To Operate |
Applicable Industries: |
Food & Beverage Factory |
Machinery Test Report: |
Provided |
Video Outgoing-inspection: |
Provided |
Warranty Of Core Components: |
1 Year |
Core Components: |
Motor, PLC, Engine, Gearbox |
Automatic: |
Yes |
After-sales Service Provided: |
Engineers Available To Service Machinery Overseas |
Advanced Technology: |
Import Assistant |
Computer Control: |
Blowing Under 1.5L Bottles |
Blowing PP/PE/PET: |
Blue |
Japan Action Valve: |
Japan Blow Valve |
Japan Cylinder: |
Infrared Heating |
Imported Frequency Converter: |
High-speed |
Gold Metal: |
Made In Huangyan |
| ITEM | UNIT | LGD-2-15 |
| Number of cavity | cavity | 2 |
| Theoretical Output | pcs/hr | 2000-2500 |
| Max.container volume | L | 1.5 |
| Max.neck diameter | mm | 45 |
| Max.container diameter | mm | 100 |
| Max.container height | mm | 330 |
| Mould Thickness | mm | 210 |
| Mould Stroke | mm | 130 |
| Stretching Stroke | mm | 120 |
| Heat Lamp Amount | pcs | 28 |
| Max.heating power | kw | 42 |
| Power of Main Blower | kw | 43 |
| Actual power consumption | kw | 10-15kw |
| Working Pressure | Mpa | 0.8 |
| Low pressure consuming | Ltr/min | 2000 |
| Blowing pressure | Mpa | ≤3.5 |
| High pressure consuming | Ltr/min | 1200 |
| Measurement of Main Blower | mm | 2700*1600*1800 |
| Measurement of elevator | mm | 1800*900*2240 |
| Weight of Main Blower | kg | 2200 |
