Product Details
Place of Origin: Zhejiang, China
Brand Name: topwin
Certification: CE
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: $6,300.00/pieces 1-2 pieces
Plastic Processed: |
PET, PP |
Condition: |
New |
Application: |
Bottle |
Year: |
2022 |
Voltage: |
Customized |
Dimension(L*W*H): |
1650x610x1550 Mm |
Hollow Part Volume: |
3000 Ml |
High Pressure Valve Brand: |
SMC |
Rotary Cylinder Brand: |
FESTO |
PLC Brand: |
Siemens |
Power (kW): |
22.4 |
Weight (KG): |
1400 KG |
Automation: |
Semi-automatic |
Warranty: |
1 Year |
Key Selling Points: |
Easy To Operate |
Showroom Location: |
Peru, Russia, Algeria, Chile, Romania, Kenya, Colombia |
Applicable Industries: |
Food & Beverage Factory |
Machinery Test Report: |
Provided |
Video Outgoing-inspection: |
Provided |
Warranty Of Core Components: |
1 Year |
Core Components: |
Motor, Pump, PLC, Pressure Vessel, Engine |
Measurement Of Main Blower: |
1650x610x1550 Mm |
Measurement Of Heater: |
2180x600x1380 Mm |
Number Of Cavity: |
2 Cavity |
Production Capacity (BPH): |
1500-1800 |
After Warranty Service: |
Online Support |
Plastic Processed: |
PET, PP |
Condition: |
New |
Application: |
Bottle |
Year: |
2022 |
Voltage: |
Customized |
Dimension(L*W*H): |
1650x610x1550 Mm |
Hollow Part Volume: |
3000 Ml |
High Pressure Valve Brand: |
SMC |
Rotary Cylinder Brand: |
FESTO |
PLC Brand: |
Siemens |
Power (kW): |
22.4 |
Weight (KG): |
1400 KG |
Automation: |
Semi-automatic |
Warranty: |
1 Year |
Key Selling Points: |
Easy To Operate |
Showroom Location: |
Peru, Russia, Algeria, Chile, Romania, Kenya, Colombia |
Applicable Industries: |
Food & Beverage Factory |
Machinery Test Report: |
Provided |
Video Outgoing-inspection: |
Provided |
Warranty Of Core Components: |
1 Year |
Core Components: |
Motor, Pump, PLC, Pressure Vessel, Engine |
Measurement Of Main Blower: |
1650x610x1550 Mm |
Measurement Of Heater: |
2180x600x1380 Mm |
Number Of Cavity: |
2 Cavity |
Production Capacity (BPH): |
1500-1800 |
After Warranty Service: |
Online Support |
| ITEM | UNIT | LGB-4-15 |
| Number of cavity | cavity | 4 |
| Theoretical Output | pcs/hr | 1800-2000 |
| Max.container volume | L | 1.5 |
| Max.neck diameter | mm | 45 |
| Max.container diameter | mm | 80 |
| Max.container height | mm | 370 |
| Mould Thickness | mm | 180 |
| Mould Stroke | mm | 170 |
| Heat Lamp Amount | pcs | 28 |
| Max.heating power | kw | 5 |
| Power of Main Blower | kw | 5.5 |
| Actual power consumption | kw | 4 |
| Working Pressure | Mpa | 0.8 |
| Low pressure consuming | Ltr/min | 600 |
| Blowing pressure | Mpa | 3 |
| High pressure consuming | Ltr/min | 1800 |
| Measurement of Main Blower | mm | 1730*800*1850 |
| Measurement of elevator | mm | 880*520*1650 |
| Weight of Main Blower | kg | 1200 |
Under normal conditions ,the blow molding machine to abroad will be packaged in wooden case. In addition ,we will also pack the machine according to the requirements of specific customers. Subject to the measurement of main blower ,we will choose corresponding wooden case, Longer is a professional mould machinery company .we will try our best to satisfy the kinds of demand of customers.
